| Model Name | VJ-1624X | |
|---|---|---|
| Print Technology | Drop-on-demand Micro Piezo Inkjet Technology | |
| Print Head | 1 | |
| Head Heights | Low:1.5mm / High:2.5mm | |
| Max. Media Width | 1625mm | |
| Max. Print Width | 1615mm | |
| Ink Type | Eco-solvent ink | |
| MSINK 3A ink | Ink Colors | KCMY-4 colors |
| Ink Volume | KCMY: 220ml / 440ml / 1000ml bag (Need dedicated adapters) | |
| Ultra Value ink | Ink colors | KCMY - 4 colors |
| Ink Volume | 1000ml bag (Need dedicated adapters) | |
| Print Resolutions | 1440/720/360dpi (12 modes as standard + 19 modes as custom**) | |
| Interface | Ethernet (10BASE-T/100BASE-TX) | |
| Media Measurements* | φ150mm/ 2' & 3' / 30kg or less | |
| Heater Control System | Pre-heater / Platen-heater / After-heater（30-50℃）, OFF | |
| Power Supply | AC 100-120 V / AC 200-240V - 60/50 Hz | |
| A-property Acoustic Power Level (Actual Measured Value) | 69.8dB or less | |
| Printer Accuracy Guaranteed Environment | Temperature: 22～30℃ Humidity: 40～60%RH (Non Condensing) | |
| Power Consumption | Operating Status: 1100W or less (main), 1200W or less (heater), In standby: 45W | |
| Machine Measurements | W 2698 x D 885.5 x H 1261mm | |
| Packing Size | Printer: W 2880 x D 1150 x H 851mm, Weight: 247kg | |
| Stand: W 2117 x D 395 x H 250mm, Weight: 38kg | ||
| Optional take-up system: W 2336 x D 341 x H 409mm, Weight: 30kg | ||
| Printer Weight | 160kg including a stand | |
| Option | Feed and take-up system VJ-16TUP80 (80kg) | |
| Take-up system VJ-16TUP30 (30kg) | ||
| 1,000ml cartridge adapter VJ-HCIPADPT | ||
| Cutter blade VJ-CB | ||
Japan based wide format printer manufacturer MUTOH Industries Ltd., represented by Mutoh Europe nv for the EMEA business area, today announced that it has obtained Greenguard Gold Certification for its US-11 series flexible UV LED inks. Refer to the following list for the printer driver's support coverage.1:Make sure to install 'MSM' on your internet-ready PC first and then connect to your Mutoh.
